4-Channel – Hi-Res Certified, Class FD, 400 W Max Power – Digital Compact Amplifier
Features
Hi-Res Audio Certified
Small Size – Big Power
45Wx4 RMS @ 4 ohms (1%THD)
100Wx4 MAX @ 4 ohms (1%THD)
High Pass and Low-Pass Filters
Gold-plated RCA Terminals
- GM-DX874
4-Channel – Hi-Res Certified, Class FD, 1200 W Max Power – Digital Amplifier $220.00$270.00 Add to Compare
- GM-A6704
4-Channel – Class AB, 1000 W Max Power – Bridgeable Amplifier $140.00 Add to Compare
- GM-DX871
1-Channel – Class D, 1600 W Max Power – Digital Amplifier $200.00$250.00 Add to Compare
- GM-A3702
2-Channel – Class AB, 500 W Max Power – Bridgeable Amplifier $85.00 Add to Compare
- GM-A5702
2-Channel – Class AB, 1000 W Max Power – Bridgeable Amplifier $130.00 Add to Compare
- GM-DX971
1-Channel – Class D, 2400 W Max Power – Digital Amplifier $470.00 Add to Compare
- GM-A4704
4-Channel – Class AB, 520 W Max Power – Bridgeable Amplifier $130.00 Add to Compare
- GM-DX975
5-Channel – Hi-Res Certified, Class FD, 2000 W Max Power – Digital Amplifier $550.00 Add to Compare
- GM-E190X2
2-Channel – Class AB, 500 W Max Power – Bridgeable Amplifier $100.00 Add to Compare
- GM-E360X4
4-Channel – Class AB, 1000 W Max Power – Bridgeable Amplifier $124.00 Add to Compare
GM-DX104
Regular price $270.00 Add to Cart #shopify-section-template–27174808256881__main-product .yv-product-slider-wrapper {padding-top: 35px;} #shopify-section-template–27174808256881__main-product .yv-checkout-btn .add_to_cart.button {border-radius: 40px;} #shopify-section-template–27174808256881__main-product .ps-widget.ps-disabled {display: none !important;} #shopify-section-template–27174808256881__main-product .ps-widget.ps-enabled {display: block; margin-top: -10px; text-align: left;} #shopify-section-template–27174808256881__main-product .ps-widget.ps-enabled span {display: inline-block; border-bottom: 1px solid #181818; line-height: 1.4; cursor: pointer; transition: 0.2s all;} #shopify-section-template–27174808256881__main-product .ps-widget.ps-enabled span:hover, #shopify-section-template–27174808256881__main-product .ps-widget.ps-enabled span:focus {border-bottom: 1px solid transparent;}
| Bridgable Yes | Class D |
| Grounding System Negative | Power Source 14.4 V DC (10.5 V to 16.0 V) |
| Protection Control system Yes | Terminal Type Removable |
| Unit Weight 1.3 lbs |
| Allowable Load Impedance 2 ohm to 8 ohm allowable | Avg Current Consumption (Amps X #Ch) 1.6 A (4 Ohms x 4ch), 1.6 A (2 Ohms x 4ch), 1.6 A (4 Ohms x 2ch Bridged) |
| Continuous-Power-Output 45 W x 4-Channel – 4 Ohm, 45 W x 4-Channel – 2 Ohm, 90 W x 2-Channel – 4 Ohm Bridged | Frequency Response Channel 10Hz to 40kHz (+0dB,-3dB) A/B Ch |
| Fuse Rating 15 A | High-Pass Crossover Frequency 80 Hz (LPF/OFF/HPF) |
| High-Pass Slope (Db/Octave) -12 dB/oct | Low-Pass Crossover Frequency 80 Hz (LPF/OFF/HPF) |
| Low-Pass Slope (Db/Octave) -12dB/oct | Maximum Power Output 100 W x 4-Channel (4 Ohm), 200 W x 2-Channel (4 Ohm Bridged) |
| Rca Inputs 4-Channel | Speaker Line Input Sensor Yes |
