4-Channel – Hi-Res Certified, Class FD, 1200 W Max Power – Digital Amplifier
Features
Hi-Res Audio Certified
100W x 4 RMS @ 4 ohms (1%THD)
150W x 4 MAX @ 4 ohms (1%THD)
Variable High Pass and Low-Pass Filters
Gold-plated RCA Terminals
Wired Bass Remote included
| Bass Boost Remote Yes | Bridgable Yes |
| Class D | Grounding System Negative |
| High Quality Audio Components Yes | Power Source 14.4V (10.8 V to 15.1 V allowable) |
| Protection Control system Yes | Terminal Type Block |
| Unit Weight 5.5 lbs |
| Allowable Load Impedance 1 ohm to 8 ohm allowable | Avg Current Consumption (amps x #ch) 3.1 A x 4-Channel – 4 Ohm,4.4 A x 2-Channel – 4 Ohm,4.4 A x 4-Channel – 2 Ohm |
| Bass Boost 50 Hz – Frequency | Continuous-Power-Output 100 W RMS x 4-Channel – 4 Ohm,125 W RMS x 4-Channel – 1 Ohm,150 W RMS x 4-Channel – 2 Ohm,300 W RMS x 2-Channel – 4 Ohm Bridged |
| Crossover Network Channel HPF – A/B Ch 40Hz-500Hz,LPF – A/B Ch 40Hz-500Hz | Crossover Network Channel Slope -12db/oct (A/B CH) |
| Frequency Response Channel 10 Hz to 50 kHz (+0dB,-3dB) A/B Ch | Fuse Rating 30A x 2 |
| Maximum Power Output 200 W x 4-Channel (4 Ohm),600 W x 2-Channel (4 Ohm Bridged) | RCA Inputs 4-Channel |
| RCA Preamp Outputs 2-ch | Speaker Line input Sensor Yes |
| THD-A/B/C Channel =/< 1% (20 Hz to 240 Hz) |
