9.0″ Modular – Hi-Res Certified, Apple CarPlay®, Android Auto™, Amazon Alexa Built-in, Bluetooth® – Multimedia Digital Media Receiver with built-in Wifi®
Features
Modular Chassis with 9.0″ HD-720 capacitive display
Apple CarPlay® (Wired, Wireless)
Android Auto™ (Wired, Wireless)
Amazon Alexa Built-in
HD Radio™ and SiriusXM-Ready™
iDatalink® Maestro™ and Metra Axxess™ compatible
PRODUCT PERFORMANCE
| Continuous Power Output 22 W x 4-Channel |
Load Impedence Allowance 4 Ohm (4 Ohm to 8 Ohm Allowable) |
| Max Power Output 50 W x 4-ch 4 ohm , 50 W x 2-ch 4 ohm 70 W X 1-ch (subwoofer) 2 Ohm |
RCA Preamp Outputs 6-ch |
| RCA Preout Voltage 4V |
RMS Power Output (CTA-2006) 14 W RMS x 4-ch 4 ohm |
GENERAL
| Detachable Face Security Fixed |
Multi-Language Display English, French, Spanish Portuguese, Chinese (Simplified) |
| Music Browser USB |
Remote Control Included |
| Steering Wheel Control Ready (Adapter Sold Separately) Yes |
DISPLAY
| Back Light LED |
Brightness Control Yes |
| Color Customization 5 display colors, 112 key colors |
Device (Non-DIN/Modular Unit) Modular, Non-DIN |
| Dimmer Automatic with vehicle illumination, Timer Controlled, Manual |
Display Off Mode Yes |
| Home Screen Customization Yes |
Monitor Mechanism Fixed |
| Resolution HD (1280 x 720) |
Screen Size/Aspect Ratio 9″/16:9 |
| Touch Screen Capacitive |
NAVIGATION
| External GPS Antenna Yes |
BLUETOOTH
| Advanced Audio Distribution Profile (A2DP) Yes |
AVRCP 1.6 |
| Built-in Bluetooth® Yes |
Dual Phone Connection Yes |
| Hands-Free Yes |
Microphone Included Included |
| Phone Registation 5-phone |
Secure Simple Pairing (SSP) Yes |
| Serial Port Profile (SPP) Yes |
TUNER
| Best Station Memory Yes |
HD Radio™ Built In, Artist Experience, Multicasting |
| Hybrid Radio Yes |
Local Seek tuning Yes |
| Presets 18 FM, 6 AM |
RDS Yes |
| SiriusXM-Ready™ (Tuner Sold Separately) Yes |
INTEGRATION
| Amazon Alexa Built In |
Android Auto™ Wireless Connection or Wired USB Connection |
| Apple® CarPlay Wireless Connection or Wired USB Connection |
CarAVassist Yes |
| Mobile Operating System Android, Apple iOS |
Music Playback (MTP) Yes |
| Pandora® With Apple CarPlay or Android Auto |
Pioneer App Compatibility CarAVAssist Android, CarAVAssist iPhone |
| Siri® Eyes Free (VR) (Internet Required) iPhone Only |
Spotify With Apple CarPlay or Android Auto |
| Voice Control Yes |
Wifi Tethering, WiFi Hotspot |
DIGITAL MEDIA PLAYBACK
| Audio Playback via USB MP3 Audio Playback, WMA Audio Playback, WAV Audio Playback (Hi-Res), AAC Audio Playback, FLAC Audio Playback (Hi-Res), DSD Audio Playback (Hi-Res) |
Audio Video Playback via USB .avi, .mpg/mpeg, .divx, .mp4, .3gp, .mkv, .flv, .wmv/.asf, .m4v, H.263, H.264, .ts/.m2ts/.mts |
| Image Display Via USB BMP, JPEG, PNG |
AUDIO
| Advanced Sound Retriever Mode-1/Mode-2/Off |
Audio Bass Boost Yes |
| Balance Yes |
Built-in Amplifier MOSFET 50 W x 4 |
| Crossover Network Mode HPF/Band Pass/LPF |
Crossover Standard Mode HPF/LPF |
| Customizable Graphic Equalizer 13 Band |
DA Converter 24 Bit |
| Digital Signal Processor Built In |
Dynamic Bass Enhancer Off/Low/High |
| Easy EQ (EEQ) Preset Equalizer Yes |
Listening Position Selector Yes |
| Loudness High/Mid/Low/Off |
Speaker Output 4-ch |
| Spectrum Analyzer Yes |
Subwoofer Control Yes |
| Time Alignment Manual |
EXPANDABILITY
| Audio Video Inputs Input 1 – Backup Camera Dedicated, Input 2 – AUX (Minijack), Input 3 – A/V or 2nd Camera, Input 4 – HDMI Micro (Type D) |
Firmware upgradability Yes |
| OEM Integration iDatalink Maestro RR, iDatalink Maestro RR2, Metra Axxess |
OTA Update Compatabile Yes |
| Parking Assist Lines Yes |
RCA-Video-Output Yes |
| USB Rear, Type-C (5 V, 3.0 Amp) |
USB Direct Control for iPhone® 5s and newer |
