6” x 9” – 2-way, 330 W Max Power, Aramid Fiber IMPP™ cone, 26mm Polyester Swivel Dome Tweeter Design – Coaxial Speakers (pair)
Features
330 Watts Maximum Power
110 Watts Nominal Power
6″ x 9″ Aramid Fiber Interlaced IMPP™ cone
26mm Polyester Soft Dome Tweeter
Frequency range: 33 Hz to 42 kHz
Speaker Impedance: 4 ohms
Speaker Efficiency: 87 (1W/1M)
Swivel Tweeter
- TS-6900PRO
6″ x 9″ – 2-way 600 W Max Power, Blended Pulp woofer Cone and 2.875″ (73 mm) Bulle… $130.00 Add to Compare
- TS-M651PRO
6.5″ – 500 W Max Power, Optimally Blended Pulp woofer Cone – PRO Series Midrange/W… $120.00 Add to Compare
- TS-B401PRO
4″ – 600 W Max Power, Field-serviceable Titanium Diaphragm, Aluminum Die-Cast Chas… $70.00 Add to Compare
- TS-A1681F
6.5″ – 4-way, 350 W Max Power, Carbon/Mica-reinforced IMPP™ cone, 1.63″ (42mm) Con… $110.00 Add to Compare
- TS-B351PRO
3.5″ – 300 W Max Power, Field-serviceable Titanium Diaphragm, Aluminum Die-Cast Ch… $60.00 Add to Compare
- TS-A879
3.5″ – 2-way, 450 W Max Power, Carbon/Mica-reinforced IMPP™ cone, 21mm PEI hard do… $70.00 Add to Compare
- TS-M801PRO
8.0″ – 700 W Max Power, Optimally Blended Pulp woofer Cone – PRO Series Midrange/W… $150.00 Add to Compare
- TS-A6991FH
6” x 9″ – 5-way, 750 W Max Power, Carbon/Mica-reinforced IMPP™ cone, 2.25″ (57mm) … $160.00 Add to Compare
- TS-A301TW
0.75″ – 450 W Max Power, PEI Hard Dome, in-line filter and multi-fit adapters incl… $55.00 Add to Compare
- TS-G650
6.5″ – 2-way, 300 W Max Power, IMPP™ cone, 30mm Tweeter – Coaxial Speakers (pair) $60.00 Add to Compare
TS-D69F
Sale price $136.00 Regular price $160.00
Strike-Through Pricing and Savings
×
USA.Pioneer may display strikethrough pricing alongside a reduced advertised price in instances where an item is subject to a “Sale,” “Instant Savings,” “Special Purchase,” or “Price Break.” The strikethrough price shown represents the price advertised for this model on or in connection with Pioneer’s website as of 5/04/2026.
Add to Cart #shopify-section-template–24289673707889__main-product .yv-product-slider-wrapper {padding-top: 35px;} #shopify-section-template–24289673707889__main-product .yv-checkout-btn .add_to_cart.button {border-radius: 40px;} #shopify-section-template–24289673707889__main-product .ps-widget.ps-disabled {display: none !important;} #shopify-section-template–24289673707889__main-product .ps-widget.ps-enabled {display: block; margin-top: -10px; text-align: left;} #shopify-section-template–24289673707889__main-product .ps-widget.ps-enabled span {display: inline-block; border-bottom: 1px solid #181818; line-height: 1.4; cursor: pointer; transition: 0.2s all;} #shopify-section-template–24289673707889__main-product .ps-widget.ps-enabled span:hover, #shopify-section-template–24289673707889__main-product .ps-widget.ps-enabled span:focus {border-bottom: 1px solid transparent;}
| Continuous Power Handling (Rms) – Watts 110 | Crossover Frequency 4300 Hz (Acoustic), 3500 Hz (Electric) |
| Frequency Response 33 Hz to 42 kHz | Maximum Peak Power Handling – Watts 330 |
| Nominal Impedance – Ohm 4-Ohm | Sensitivity (1W/1M) 87dB (+- 1.5dB) |
| System-Type Coaxial 2-way, Soft Dome – Tweeter |
| Cut Out dimensions 8-3/4″ x 6″ | Mounting Depth 2-7/8″ |
| Speaker Grill Included | Tweeter Dimensions 1.03″ |
| Tweeter – Swivel Type Yes | Woofer Dimensions 6″ x 8″ |
| Basket Material Metal | Cone Material Aramid Fiber Interlaced Injection Molded Polypropylene (IMPP) |
| Damper Poly cotton Aramid | Diaphragm Material Polyester – Tweeter |
| Magnet Material Ferrite – Speaker, Neodymium – Tweeter | Magnet Weight 15.2 oz – Speaker, 0.2 oz – Tweeter |
| Surround Material Butyl Rubber | Surround Type Rolled |
| Voice Coil Material Glass Imide | Voice Coil wire Copper |
| Wire Terminals Lug Type |
