CD Audio Receiver with Enhanced Audio Functions, front USB connection, Pioneer ARC App Compatibility and MIXTRAX®.
Features
Pioneer ARC App (USB)
Android™ Compatibility
MIXTRAX®
MOSFET 50W x 4
1 pair of Preouts
PRODUCT PERFORMANCE
| Continuous Power Output 22 W x 4-Channel |
Load Impedence Allowance 4 Ohm (4 Ohm to 8 Ohm Allowable) |
| Max Power Output 50 W x 4-ch 4 ohm ,50 W x 2-ch 4 ohm 70 W X 1-ch (subwoofer) 2 Ohm |
RCA Preamp Outputs 2-ch |
| RCA Preout Voltage 2V |
RMS Power Output (CTA-2006) 14 W RMS x 4-ch 4 ohm |
GENERAL
| Detachable Face Security Detachable |
Multi-Language Display English, French, Spanish |
| Music Browser USB |
Remote Control Included |
| Rotary Volume Control Yes |
DISPLAY
| Back Light LED |
Brightness Control Yes |
| Color Customization Fixed |
Device Display VA LCD (2-Line) |
| Device (Non-DIN/Modular Unit) 1-DIN |
Dimmer Timer Controlled, Manual |
BLUETOOTH
| Advanced Audio Distribution Profile (A2DP) No |
AVRCP No |
| Built-in Bluetooth® No |
Dual Phone Connection No |
| Guest Mode No |
Hands-Free No |
| Microphone Included No |
Secure Simple Pairing (SSP) No |
| Serial Port Profile (SPP) No |
Sound Retriever Air No |
TUNER
| Best Station Memory Yes |
Local Seek tuning Yes |
| Presets 18 FM, 6 AM |
RDS Yes |
INTEGRATION
| Mobile Operating System Android – Wired |
Music Playback (MTP) Yes |
| Pioneer App Compatibility ARC Android OS version 4.1 to 7.1.2 |
DIGITAL MEDIA PLAYBACK
| Audio Playback via CD MP3 Audio Playback,WAV Audio Playback,WMA Audio Playback |
Audio Playback via USB MP3 Audio Playback,WMA Audio Playback,FLAC Audio Playback (Hi-Res),WAV Audio Playback (Hi-Res) |
AUDIO
| Advanced Sound Retriever Mode-1/Mode-2/Off |
Audio Bass Boost Yes |
| Balance Yes |
Built-in Amplifier MOSFET 50 W x 4 |
| Crossover Standard Mode HPF/LPF |
Customizable Graphic Equalizer 5 Band |
| DA Converter 24 Bit |
Digital Signal Processor Built In |
| Easy EQ (EEQ) Preset Equalizer Yes |
Loudness High/Mid/Low/Off |
| Source Level Adjuster Yes |
Speaker Output 4-ch |
| Subwoofer Control Yes |
EXPANDABILITY
| Audio Video Inputs Input 2 – AUX (Minijack) |
USB Front Type-A (5V, 1-1/2 A) |
